Rediscover the comfort in your life with the convenience of usage and superior insulation features of Pimapen Dynamic Sliding, developed simultaneously with Europe.
Full harmony with your architecture thanks to laminated color alternatives resistant to tough weather conditions requiring a lower level of maintenance. In addition to unlimited options of colors, it is possible to deliver a full harmony with the façade of your building by means of applying different laminated colors for the internal and external surfaces.
Unlimited Options of Colors
Profile
Dynamic Sliding Window and Door systems: The frame profile is 149 mm wide, 65 mm high, and has 6 chambers. The sash profile is designed with a width of 76 mm, 5 chambers, and dimensions for 20 axes hardware. The central reinforcement profile is 76 mm wide with 5 chambers, providing high insulation among simple sliding systems.
Design
The Dynamic Sliding System, developed simultaneously with Europe, is the optimal solution to create environments that do not compromise on the view.
Glazing Combinations
Specially designed moldings are available to ensure an aesthetic appearance in profile and glass joints. The molding feature allows for improved sound-insulated, secure, and sun-protected glass applications with widths of 24-30-36-44-52 mm for double glass, triple glass units, and panels.
Equipment
Thanks to its hook lock mechanism, it provides high security by standing out from its counterparts. The Dynamic Sliding System is advantageous with its ease of use and low maintenance costs compared to other sliding systems.
Technical Specifications
- Profile Width: 149 mm
- Number of Cubicles: 5
- Gasket System: Internal-External Gasket System
- Gasket Type - Color: TPE - Gray / Black
- Sash Bar: Single Claw - PCE Gasketed
- Glazing Thicknesses (mm): 24, 30, 36, 44, 52
- Project Class: B Class (TS EN 12608-1)
